DOM Tubes

Drawn Over Mandrel (DOM) is made from carbon and alloy, electric resistance welded steel tube with all of the flash removed. Tubing is further processed by cold drawing the semi-finished tube through dies and over mandrels simultaneously to achieve the finished dimensions.

DOM STEEL TUBING MANUFACTURING PROCESS

The manufacturing process for DOM round steel tubing begins with coils of steel, which are slit to the proper width for the desired tube size. The strip is cold formed and passed through an electric resistance welder which joins the edges together, under pressure, to complete the tubular shape. After testing the weld’s integrity, the tubing is cut to length for further processing. The cold-drawing process creates a uniform, precision product with substantially improved tolerances, surface finish and tensile strength, increased hardness, and good machinability. In this process, the tube is cleaned and annealed, and one end of each length is squeezed to a point so it can be gripped by the drawing mechanism.

The tube is then drawn through one or more dies and over mandrels. This reduces the diameter of the tube and thins its walls to the required dimensions in a controlled fashion to provide the qualities desired in the finished product. Metallurgically, drawing improves the tube’s concentricity, tensile strength, hardness, and machinability. Close dimensional accuracy is achieved through tight control of both outside and inside diameters.

These tubes are used for various applications like :

Size Range
